JRS1-09-25 thermal relay

Product Details

♦Two types (bimetallic & electronic) for different protection needs. ♦Multiple protections: overload, phase - loss & unbalanced three - phase. ♦User - friendly: A1, A2 terminals for easy wiring. ♦High reliability with durable materials. ♦Use: Protect AC motors in industry, prevent overload in production lines.

Product Parameters

Application

JRS1(LR1) series thermal relay is suitable for using in the circuits rated voltage up to 660V,rated current 93A AC50Hz or 60Hz,for over-voltage protection of A.C. motor. The relay has the defferential mechanism and temperature compensation and can plug in CJX2 seriesAC contactor.

Motion characteristic:Three-phase balance motion time

Phase-losing motion characterisic

Specifications

Outline mouting size

JRS1-09-25 thermal relay
